Rental Equipment

Skidsteer 3'

4 HR-$229 and 24 HR-$289

Skidsteer 3
A. LENGTH WITH BUCKET 8.4 ft in 2560 mm
B. WIDTH OVER TIRES 3 ft in 900 mm
C. HEIGHT TO TOP OF CAB 6 ft in 1814 mm
D. WHEELBASE 2.4 ft in 722 mm
E. GROUND CLEARANCE 5.5 in 140 mm
F. LENGTH W/O BUCKET 6.3 ft in 1918 mm
G. CLEARANCE AT MAX LIFT AND DUMP 6.2 ft in 1882 mm
H. REACH AT MAX LIFT AND DUMP 18.5 in 469.9 mm

Specification

Engine
MODEL D1005- E 2B-BC -3
GROSS POWER 22.5 hp 16.8 kw
Operational
OPERATIONAL WEIGHT 2708 lb 1228.3 kg
FUEL CAPACITY 6.5 gal 24.6 L
MAX SPEED 6.5 mph 10.5 km/h
Loader
OPERATING LOAD RATING 700 lb 317.5 kg
TIPPING LOAD 1405 lb 637.3 kg
Hydraulic
PUMP FLOW CAPACITY 10 gal/min 37.9 L/min
Dimensions
LENGTH WITH BUCKET 8.4 ft in 2560 mm
LENGTH W/O BUCKET 6.3 ft in 1918 mm
WIDTH OVER TIRES 3 ft in 900 mm
HEIGHT TO TOP OF CAB 6 ft in 1814 mm
CLEARANCE AT MAX LIFT AND DUMP 6.2 ft in 1882 mm
WHEELBASE 2.4 ft in 722 mm
GROUND CLEARANCE 5.5 in 140 mm
REACH AT MAX LIFT AND DUMP 18.5 in 469.9 mm
TURNING RADIUS FROM CENTER – MACHINE REAR 61.3 in 1557mm

Skidsteer 3'

4 HR-$229 and 24 HR-$289

Skidsteer 3
A. LENGTH WITH BUCKET 8.4 ft in 2560 mm
B. WIDTH OVER TIRES 3 ft in 900 mm
C. HEIGHT TO TOP OF CAB 6 ft in 1814 mm
D. WHEELBASE 2.4 ft in 722 mm
E. GROUND CLEARANCE 5.5 in 140 mm
F. LENGTH W/O BUCKET 6.3 ft in 1918 mm
G. CLEARANCE AT MAX LIFT AND DUMP 6.2 ft in 1882 mm
H. REACH AT MAX LIFT AND DUMP 18.5 in 469.9 mm

Specification

Engine
MODEL D1005- E 2B-BC -3
GROSS POWER 22.5 hp 16.8 kw
Operational
OPERATIONAL WEIGHT 2708 lb 1228.3 kg
FUEL CAPACITY 6.5 gal 24.6 L
MAX SPEED 6.5 mph 10.5 km/h
Loader
OPERATING LOAD RATING 700 lb 317.5 kg
TIPPING LOAD 1405 lb 637.3 kg
Hydraulic
PUMP FLOW CAPACITY 10 gal/min 37.9 L/min
Dimensions
LENGTH WITH BUCKET 8.4 ft in 2560 mm
LENGTH W/O BUCKET 6.3 ft in 1918 mm
WIDTH OVER TIRES 3 ft in 900 mm
HEIGHT TO TOP OF CAB 6 ft in 1814 mm
CLEARANCE AT MAX LIFT AND DUMP 6.2 ft in 1882 mm
WHEELBASE 2.4 ft in 722 mm
GROUND CLEARANCE 5.5 in 140 mm
REACH AT MAX LIFT AND DUMP 18.5 in 469.9 mm
TURNING RADIUS FROM CENTER – MACHINE REAR 61.3 in 1557mm
