With a productive combination of high engine power and best-in-class breakout force while maintaining compact skid steer loader dimensions, the CASE SR175 skid steer will boost your performance and productivity. Built-in serviceability along with easy accessible filters and engine fluids make maintenance on the SR175 model a breeze. The new DOC-Only solution provides a more convenient and higher performance alternative to meet Tier 4 emissions regulations.
OPERATOR ENVIRONMENT
- ROPS/FOPS Level 1 canopy w/ side screens
- Keyed start ignition
- Tilt ROPS/FOPS
- Rear window w/ emergency escape
- Suspension Seat, vinyl w/ 2 in (51 mm) retractable 3 point lap seat belt
- Hand and foot throttle
- Alarm package – back-up and horn
- Rearview mirror
- Headliner
- Dome Light
- Top window
- Cup holder
- 12V Power plug socket
- Foot rest
- Seat pocket
- Padded seat bar w/ integral armrests
- Loader control lockout system
- Electric parking brake control
- Operator’s compartment floor cleanout
- Proportional auxiliary hydraulic control – on joystick
- Advanced Instrument Cluster w/: Digital hour meter, Tachometer, Fuel level LCD bar graph w/ alarm, Diagnostic features, Security lockout
- Warning lights with alarms: Engine coolant temperature, Engine oil pressure, Engine malfunction, Hydraulic charge pressure, Hydraulic filter restriction
- Hydraulic oil temperature: Critical system stop, Engine system, Hydraulic system, Electrical and diagnostic system
- Warning alarms: Battery voltage – plus display, Oil service
- Indicator light: Engine preheat, Parking brake, Seat bar reminder
ENGINE
- ISM N844LTA-DI-F-50 diesel
- 135.2 CID (2.2 L) Turbo
- Tier 4 Final Certified
- Spark Arresting Diesel Oxidation Catalyst (DOC) muffler
- Charged Air Cooler (CAC)
- High Pressure Common Rail (HPCR) fuel injection
- Horsepower: Gross: 67 hp (50.0 kW), Net: 64 hp (47.7 kW), Peak torque: 153 lb·ft (208 N·m)
- 120 amp alternator
- Dual element air cleaner
- Organic Acid Technology (OAT)
- Anti-freeze solution to -34º F
- Fuel tank – 20 gal (U.S.)
- Over and under radiator and oil cooler
- 3-stack after cooler/radiator/oil cooler configuration
- Glow plugs
- Integral engine oil cooler
- Fuel filter with water trap
- 925 CCA 12V battery
- Master electrical disconnect
DRIVETRAIN
- 2-speed hydrostatic four wheel drive
- ASA #80 drive chain
- SAHR disc parking brake
HYDRAULICS
- Auxiliary hydraulics: @ 3,050 psi (210 bar) – 20.6 gpm (78.0 L/min)
- 6 micron oil filtration system
- 3-spool loader control valve
- Auxiliary hydraulic disconnects, ISO flat-face – connect-under-pressure with case drain
- Hydraulic circuit pedal lock
- Auxiliary function lockout override
- Loader lift lockout override
- Heavy-duty hydraulic oil cooler
- Loader arm float position
- Loader function lockout system
LOADER
- Auxiliary front electric control
- Manual attachment coupler
- Radial lift geometry
- Loader lift arm support strut
TIRES
- 10 X 16.5 Heavy duty
OTHER STANDARD FEATURES
- Halogen lights – 2 front, 2 side, 2 rear flood
- Heavy duty front lights
- Pre-wired for rotating beacon
- Lockable service access hood
- Single-point daily service
- Rear tail lights
- Remote oil drain
- Remote oil and fuel filters
- Block heater
- Debris ingression sealing
- Mounting points for add-on counterweights
