ENGINE
Net Power 23.6 HP Operating Weight 7817 lb EU: CE Plate Weight with Canopy*** 6791 lb Minimum Operating Weight with Canopy* 6670 lb Maximum Operating Weight with Canopy** 7552 lb Dig Depth 116.1 in Boom Height – Shipping Position 75.6 in Tail Swing with Counterweight 35 in Track Belt/Shoe Width 11.8 in Maximum Reach 206.3 in Boom In Reach 74.2 in Boom Swing – Right 34.3 in Tail Swing 33.3 in Maximum Dump Clearance 130.3 in Ground Clearance 12.2 in O/A Undercarriage Length 81.5 in O/A Shipping Height 97.6 in Track Width – Expanded 61 in Maximum Blade Depth 21.1 in Maximum Reach – Ground Level 201.2 in Stick Length 61.4 in Overall Shipping Length* 179.5 in Maximum Dig Height 183.1 in Swing Bearing – Height 22.4 in BLADE
Height 13.8 in Width 61 in Dig Depth 104.3 in
Hourly | 4 hours, 24 hours |
---|
